Asus Rog Crosshair 2006 soc AM5 DDR5 X870E Atx 90MB1PP0-M0EAY0

ROG Crosshair 2006.

The ROG Crosshair 2006 celebrates the 20th anniversary of the very first ROG motherboard with a retro-inspired copper color design and signature OLED animation.

This flagship platform also offers advanced power delivery and cutting-edge memory technologies, blending heritage with modern performance.

Model.

ROG CROSSHAIR 2006.

Socket AM5.

CPU.

AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors*.

* Refer to for CPU support list.

Chipset.

AMD X870E.

Memory.

4 x DIMM slots, max. 256GB, DDR5.

Supports up to.

8600+MT/s(OC)**/8200+MT/s(OC)*** with Ryzen™ 9000 Series Processors,.

9600+MT/s(OC)**/9200+MT/s(OC)*** with Ryzen™ 8000 Series Processors,.

8000+MT/s(OC)**/8000+MT/s(OC)*** with Ryzen™ 7000 Series Processors,.

ECC and Non-ECC, Un-buffered DIMM*".

Dual channel memory architecture.

Supports AMD Extended Profiles for Overclocking (EXPO™).

Supports DIMM Fit and DIMM Fit Pro.

NitroPath DRAM Technology.

ASUS Enhanced Memory Profile (AEMP).

* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit Adjustments will be made based on the specifications of mass-produced memory products available on the market.

* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

** Max Manual Overclocking: Achievable with advanced BIOS configuration and potentially specialized hardware.

Passed AIDA64 memory benchmark at this frequency, verifying read/write bandwidth.

Results may vary according to system components.

*** XMP/EXPO/AEMP Profiles: Rated memory module speeds require setting the BIOS perormance profile.

Results may vary according to system components and can be impacted when four DIMM slots are used.

For XMP/EXPO/AEMP profile settings, please visit.

Graphics.

1 x HDMI™ port*.

2 x USB4 (40Gbps) ports support USB Type-C display outputs***.

* Available only on processors featuring integrated graphics.

Graphics specifications may vary between CPU types.

Please refer to AMD CPU specifications.

*Supports 4K@60Hz as specified in HDMI 2.1.

**Supports max. 4K@60Hz as specified in DisplayPort 1.4a.

***The display function of the Type-C port depends on the resolution supported by your processor or graphics card.

For more details, please refer to the product manual.

Expansion Slots.

AMD Ryzen™ 9000 & 7000 Series Desktop Processors*.

2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes)**.

AMD Ryzen™ 8700 & 8600 & 8400 Series Desktop Processors*.

2 x PCIe 4.0 x16 slots (only supports PCIEx16(G5)_1 & total bandwidth for x8, PCIEx16(G5)_2 will run at PCIe 3.0 x4).

AMD Ryzen™ 8500 & 8300 Series Desktop Processors*.

2 x PCIe 4.0 x16 slots (only supports PCIEx16(G5)_1 & total bandwidth for x4, PCIEx16(G5)_2 will run at PCIe 3.0 x4).

* Please check the PCIe bifurcation table on the support site (.

* Specifications vary by CPU types.

** When PCIEX16_1 runs at PCIe 5.0 x16, PCIEX16_2 will run at PCIe 3.0 x4.

The bandwidth can be altered in the BIOS.

- To ensure compatibility of the device installed, please refer to for the list of supported.

Storage.

Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*.

AMD Ryzen™ 9000 & 7000 Series Desktop Processors.

M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode).

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)*.

AMD Ryzen™ 8700 & 8600 & 8400 Series Desktop Processors.

M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode).

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)*.

AMD Ryzen™ 8500 & 8300 Series Desktop Processors.

M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode).

M.2_2 slot (Key M), type 2242/2260/2280 (Not supports).

AMD X870E Chipset.

M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode).

M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode).

M.2_5 slot (Key M), type 2230 (supports PCIe 4.0 x2 mode).

2 x SATA 6Gb/s ports.

ASMedia ASM1162 Controller.

2 x SATA 6Gb/s ports.

*Specifications vary by CPU types.

** The USB4 40Gbps ports and the M.2 Socket 3 slot (M.2_2) share the available bandwidth.

When a device is installed in the M.2_2 slot, both the USB4 controller and the M.2_2 slot operate at up to x2 mode.

By configuring the M.2_2 slot in the BIOS, the M.2_2 slot can operate at up to x4 mode.

However, enabling this setting will disable the USB4 40Gbps ports.

RAID Support.

AMD RAIDXpert2 Technology.

Ryzen™ 9000 & 8000 & 7000 Series Processors: RAID 0/1/5/10*.

* SATA ports from ASM1162 cannot support RAID.

Ethernet.

1 x Realtek 10Gb Ethernet.

1 x Realtek 5Gb Ethernet.

ASUS LANGuard.

Wireless & Bluetooth.

"Wi-Fi 7 (MediaTek MT7927).

2x2 Wi-Fi 7* (802.11be).

Supports 2.4/5/6GHz frequency band**.

Supports Wi-Fi 7 320MHz bandwidth.

Bluetooth v5.4 (suppport LE Audio)***.

*Wi-Fi features may vary depending on the operating
