Asus Prime B860M-A Wifi

Základné dosky radu ASUS PRIME sú odborne navrhnuté tak, aby naplno využili potenciál najnovších procesorov Intel Core™ Ultra (séria 2).

Základná doska PRIME B860M-A WIFI, ktorá sa môže pochváliť robustným dizajnom napájania, komplexnými riešeniami chladenia a inteligentnými možnosťami ladenia, poskytuje používateľom a výrobcom počítačov svojpomocne rad optimalizácií výkonu prostredníctvom intuitívnych funkcií softvéru a firmvéru.

Je navrhnutý tak, aby bol pripravený na počítač s pokročilou AI a ponúkal výkon a konektivitu potrebnú pre náročné aplikácie AI.

Špecifikácia:.

CPU.

Support Intel Core™ Ultra Processors (Series 2) , LGA1851*.

Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0**.

* Refer to for CPU support list.

** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset.

Intel B860 Chipset.

Memory.

4 x DIMM slots, max. 256GB, DDR5.

Supports up to 8400+MT/s (OC), Non-ECC,Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*".

Dual channel memory architecture.

DIMM Fit.

Supports Intel Extreme Memory Profile (XMP) memory module.

ASUS Enhanced Memory Profile III(AEMPIII).

* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit.

* Adjustments will be made based on the specifications of mass-produced memory products available on the market.

* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Graphics.

2 x DisplayPort**.

1 x HDMI™ port***.

* Graphics specifications may vary between CPU types.

Please refer to for any updates.

** Supports max. 4K@60Hz as specified in DisplayPort 1.4.

*** Supports 4K@60Hz as specified in HDMI 2.1.

***** VGA resolution support depends on processors" or graphic cards" resolution.

******While installing the operating system, please ensure that your monitor is connected to the HDMI port on the back I/O panel or to a discrete graphics card.

Expansion Slots.

Intel Core™ Ultra Processors(series 2)*.

1 x PCIe 5.0 x16 slot.

Intel B860 Chipset**.

1 x PCIe 4.0 x16 slot (supports x4 mode).

1 x PCIe 4.0 x1 slot.

- To ensure compatibility of the device installed, please refer to for the list of supported peripherals.

Storage.

Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*.

Intel Core™ Ultra Processors (Series 2) *.

M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode).

Intel B860 Chipset.

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 modes).

4 x SATA 6Gb/s ports.

* Intel Rapid Storage Technology supports SATA RAID 0/1/5/10.

Ethernet.

1 x Realtek 2.5Gb Ethernet.

ASUS LANGuard.

Wireless & Bluetooth.

Wi-Fi 6E.

2x2 Wi-Fi 6E (802.11ax).

Supports 2.4/5/6GHz frequency band*.

Bluetooth v5.3**.

* WiFi 6E 6GHz regulatory may vary between countries, supported only in Windows 11 or later.

** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer"s website for the latest specifications.".

USB.

Rear USB (Total 8 ports).

1 x USB 20Gbps port (1 x USB Type-C).

1 x USB 10Gbps port (1 x Type-A ).

2 x USB 5Gbps ports (2 x Type-A).

4 x USB 2.0 ports (4 x Type-A)**.

Front USB (Total 5 ports).

1 x USB 10Gbps connector (supports USB Type-C ).

1 x USB 5Gbps header supports 2 additional USB 5Gbps ports.

1 x USB 2.0 header supports 2 additional USB 2.0 ports.

* USB Type-C power delivery output: max. 5V/3A.

** USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth.

Audio.

"Realtek 7.1 Surround Sound High Definition Audio CODEC*.

- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking.

- Supports up to 24-Bit/192 kHz playback".

Audio Features.

- Audio Shielding.

- Premium audio capacitors.

- Dedicated audio PCB layers.

** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Back Panel I/O Ports.

1 x USB 20Gbps port (1 x USB Type-C).

1 x USB 10Gbps port (1 x Type-A).

2 x USB 5Gbps ports (2 x Type-A).

4 x USB 2.0 ports (4 x Type-A ).

2 x DisplayPort.

1 x HDMI™ port.

1 x Wi-Fi module.

1 x Realtek 2.5Gb Ethernet port.

3 x Audio jacks.

Internal I/O Connectors.

Fan and Cooling Related.

1 x 4-pin CPU Fan header.

1 x 4-pin CPU OPT Fan header.

1 x 4-pin AIO Pump header.

3 x 4-pin Chassis Fan headers.

Power Related.

1 x 24-pin Main Power connector.

1 x 8-pin +12V CPU Power connector.

Storage Related.

2 x M.2 slots (Key M).

4 x SATA 6Gb/s ports.

USB.

1 x USB 10Gbps connector (supports USB Type-C ).

1 x USB 5Gbps header supports 2 additional USB 5Gbps ports.

1 x USB 2.0 header supports 2 additional USB 2.0 ports.

Miscellaneous.

3 x Addressable Gen 2 headers.

1 x Aura RGB header.

1 x Clear CMOS header.

1 x Chassis Intrusion header.

1 x COM Port header.

1 x Front Panel Audio header (F_AUDIO).

1 x S/PDIF Out header.

1 x SPI TPM header (14-1 pin).

1 x 10-1 pin Front System Panel header.

1
